Chinese Top Brand Zoomlion 25 Ton Luffing-Jib Tower Crane L400-25 in Dubai for Hot Sale

Certification
China Sichuan Deyike New Construction Development Co., Ltd. certification
China Sichuan Deyike New Construction Development Co., Ltd. certification
I'm Online Chat Now

Chinese Top Brand Zoomlion 25 Ton Luffing-Jib Tower Crane L400-25 in Dubai for Hot Sale

Chinese Top Brand Zoomlion 25 Ton Luffing-Jib Tower Crane L400-25 in Dubai for Hot Sale
Chinese Top Brand Zoomlion 25 Ton Luffing-Jib Tower Crane L400-25 in Dubai for Hot Sale Chinese Top Brand Zoomlion 25 Ton Luffing-Jib Tower Crane L400-25 in Dubai for Hot Sale Chinese Top Brand Zoomlion 25 Ton Luffing-Jib Tower Crane L400-25 in Dubai for Hot Sale Chinese Top Brand Zoomlion 25 Ton Luffing-Jib Tower Crane L400-25 in Dubai for Hot Sale Chinese Top Brand Zoomlion 25 Ton Luffing-Jib Tower Crane L400-25 in Dubai for Hot Sale

Large Image :  Chinese Top Brand Zoomlion 25 Ton Luffing-Jib Tower Crane L400-25 in Dubai for Hot Sale

Product Details: Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: US$187,000.00 - 252,000.00
Payment Terms: T/T
Contact Now Chat Now

Chinese Top Brand Zoomlion 25 Ton Luffing-Jib Tower Crane L400-25 in Dubai for Hot Sale

Description
Usage: Used Working Temperature: -20℃ To 40℃
Model: TC6013-8 Key Word: Zoomlion Second Hand 6012-6 Tower Cranes
Max Load: 6tons Serive: 24 On Line
Operating Weight: 80 Tons Report: Provide
Boom Support Method: Flat-head Tower Crane Power Supply: 380V/50Hz
Free Standing Height: 60m Type: 6010-8
Origin: China Country: China
Shipmnet Way: Air Sea
Highlight:

Zoomlion 25 ton tower crane

,

used luffing-jib tower crane

,

L400-25 tower crane Dubai

Basic Info.

Model NO.
L400-25
Maximum Lifting Height
50-100m
Maximum Lifting Weight
20t
Installation
Overall Rapid Disassembly
Moving Type
Fixed
Type
Top-Slewing Crane
Transport Package
by Sea
Trademark
ZOOMLION
Origin
China
HS Code
84262000
Production Capacity
500/Month

Product Description

Chinese Top Brand Zoomlion 25 Ton Luffing-Jib Tower Crane L400-25 In Dubai for Hot Sale



1. Performance parameters of L400-25: performance parameters and technical indexes reach both domestic and international advanced level.
• Max. jib length: 60m; Jib length under different assembling modes can decrease progressively by 5 meters and the Min. jib length is 30 meters.
• Max. lifting capacity 25t;
• Hoisting capacity at jib tip:4.71t;
• Max. lifting moment 400t.m;
• Hoisting mechanism: H90FL125-910; power:90 kW; rope capacity: 910m;
• Slewing mechanism: HPW75F1.130A/HPW75F2.130A;power:3×145N.m(equal to 3×7.5kW)
• Trolleying mechanism: L60FL80; power: 60kW
2. Electrical control system
With PLC control, the electrical control system enjoys better reliability and safety. Produced by professional manufacturers with advanced foreign technology, the electrical elements feature service lives that are 3 or 4 times longer than that of domestic products, less faults, easy maintenance and repair as well as reliable operation.

3. Technical features
• The crane boasts of multiple operation modes and wide application;
• The complete machine adopts internationally well-received beautiful shape;
• The crane features high working speed and excellent speed regulation performance. Stepless speed regulation by frequency control, the world's most advanced solution, is adopted for the trolleying mechanism and slewing mechanism, thus ensuring more stable and reliable operation ;
• The cab is independently installed externally with good vision and large inner space, thus offering a good working environment for operators;
• A variety of safety devices are equipped, which are all mechanical or mechatronic products that are applicable to severe working conditions, so as to ensure the tower crane's reliable operation.


 Rated liftingmoment (t.m) 400
 Max. lifting    height (m) Free-standing    stationary crane 49.95
Anchored crane 205.55
Working radius    (m)      Max. working    radius    60
Min. working    radius     3.8
Max. lifting    capacity (t) 25
       Hoisting    mechanism  Rope    fall α=2 α=4
Speed (m/min) 0~37.5 0~75 0~94 0~18.8 0~37.7 0~47
Lifting weight    (t) 12.5 6.25 3 25 12.5 6
Power (kW) 90
Slewing    mechanism Speed (m/min) 0~0.72
Power (kW) 3×7.5kW
Trolleying    mechanism Speed (m/min) 3 (15°~85°)
Power (kW) 60

Chinese Top Brand Zoomlion 25 Ton Luffing-Jib Tower Crane L400-25 in Dubai for Hot Sale 0Chinese Top Brand Zoomlion 25 Ton Luffing-Jib Tower Crane L400-25 in Dubai for Hot Sale 1
company profile

Deyi Kexin Construction and Development Co., Ltd. was established in 2005. We have been deeply engaged in the field of construction machinery for 20 years, specializing in the leasing, domestic and international sales, and technical services of construction machinery and second-hand equipment. At the same time, we cooperate with sister companies and have a certain capacity for the research and development and production of new machines. The company regards the practicality, stability, durability and low failure rate of its products as its hard power. With the mission of "driven by the dedication of technology and industry, serving the world", we are committed to providing customers with solutions for the entire life cycle of construction machinery and equipment.


Equipment coverage: Including excavators (brands such as Caterpillar, Komatsu, Sany, Hyundai, Shandong Lingong, etc.), tower cranes (Zoomlion, XCMG, Sany, Sichuan Construction, Hongsheng, Zhongxing), loaders, aerial work platforms, water sprinklers, garbage sweeping loaders, trucks, etc., meeting the demands of multiple scenarios such as construction, municipal works, road and bridge projects, and logistics.


Global market: Through domestic and foreign agents and Internet e-commerce platforms, the equipment is exported to Southeast Asia, the Middle East, Africa, North America, Europe and America, and countries and regions along the Land and Sea Silk Roads. The annual transaction volume continues to rise.


Relying on 20 years of industry accumulation, the company will continue to expand the research and development of intelligent equipment, deepen global supply chain cooperation, and build a five-in-one construction machinery ecosystem platform of "leasing + sales + production + marketing + technical services" to help customers reduce costs and increase efficiency.
